Brakes for engines and gearboxes

In line with the motors and gearboxes, Rollstar produces its own disc and disc brakes, which can be adjusted to the desired holding torque.

Disc brakes

The spring-pressure multi-disc brakes are designed according to the modular system and are hydraulically ventilated. They find their application focus as safety or holding brakes in drives of all kinds.

Depending on the design, the minimum air pressure is between 15 and 40 bar, with a maximum of 300 bar. The brakes are equipped with the friction pairing steel/sintered bronze for wet and dry running. In the event of a hydraulics failure, emergency manual ventilation can be carried out by a hydraulic hand pump.

The Rollstar multi-disc brake is available in different sizes and can secure a maximum holding torque of up to 6400 Nm.

Disc brakes and special solutions

In addition to the standard versions, we can of course also implement solutions that are specifically tailored to customer applications. For example, a disc brake mounted between the motor and the gearbox to enable dynamic braking.

3D models for construction

We make the CAD data of our products available on the TraceParts platform.

Engineers and planners can thus integrate our motors, gears and brakes directly into their design. We are happy to support you with questions about the technical solutions.
